High-performance C102-LMS-25 cast iron external gear pump with 100 cc/rev displacement, designed for heavy-duty industrial and mobile hydraulic applications requiring high pressure and reliability.
| C102 Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 100 cc/rev, 90 cc/rev, 112 cc/rev |
| Rated Pressure | 17 MPa (2465 psi), 20 MPa (2900 psi) |
| Max Pressure | 25 MPa (3625 psi) |
| Rated Speed | 2500 r/min |
| Max Speed | 2500 r/min |
| Rotation | L: Left (counter-clockwise), R: Right (clockwise) |
| Material | Cast Iron |
| Structure | External Gear Pump |
| Flange Version | ISO-4 Mounting Holes |
| Shaft Type | H: Rectangle Spline |
The C102-LMS-25 is a premium 100 cc/rev external gear pump engineered for demanding global markets. Constructed from high-strength cast iron, it delivers a rated pressure of up to 20 MPa (2900 psi) and peak pressures of 25 MPa (3625 psi) at speeds up to 2500 r/min. Key features include a standard ISO 4-hole mounting flange and a durable rectangle spline shaft for efficient power transmission. This pump is ideal for dump trucks, material handling equipment, and construction machinery. As a leading manufacturer, we offer OEM, private labeling, and custom manufacturing services, seeking long-term partnerships with distributors and wholesalers worldwide. Its robust design ensures long service life and high volumetric efficiency in harsh environments.
