The CBHW-UNI-80 is a high-performance 80 cc/rev bidirectional hydraulic gear pump crafted from durable cast iron. Designed for heavy-duty applications, it delivers rated pressures up to 22 MPa and supports both ISO and UNI mounting standards, making it a versatile choice for global industrial and mobile machinery.
| CBHW Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 32 cc/rev, 50 cc/rev, 63 cc/rev, 80 cc/rev, 100 cc/rev, 25 cc/rev, 43 cc/rev, 90 cc/rev |
| Rated Pressure | 20 MPa (2900 psi), 22 MPa (3190 psi) |
| Max Pressure | 23 MPa (3335 psi), 25 MPa (3625 psi) |
| Rated Speed | 2200 r/min |
| Max Speed | 2500 r/min |
| Rotation | /: (Bidirectional) |
| Structure | External Gear Pump, Internal Gear Pump |
| Material | Cast Iron |
| Shaft Type | H: Rectangle Spline |
| Flange Version | ISO-4 Mounting Holes, UNI-3 Mounting Holes |
Our CBHW-UNI-80 80 cc/rev Hydraulic Gear Pump is engineered for reliability and high-pressure performance. Key features include: 1. Robust Construction: High-strength cast iron body ensures durability under extreme working conditions. 2. Versatile Design: Supports both Internal and External gear structures with a bidirectional rotation capability, offering maximum installation flexibility. 3. Dual Mounting Options: Compatible with ISO-4 and UNI-3 mounting holes, featuring a rectangular spline shaft for secure power transmission. 4. High Efficiency: Operates at a rated pressure of 22 MPa (3190 psi) with peak pressures reaching 25 MPa, suitable for demanding agricultural, construction, and material handling tasks. This pump is ideal for OEMs and distributors seeking premium quality components for forklifts, wheel loaders, and specialized industrial vehicles.
