High Performance 8 Spool Directional Valve | Customizable for Hydraulic Systems

Control Method:Solenoid and Joystick

Spool:8 Spool

Rated Flow:90 L/min (23.8 US gpm)

Max Pressure:200 bar (2900 psi)

Inlet Port:G1/2

Outlet Port:G3/4

Port Size:G1/2

Vendor:BXHS

Product Type:Sectional Directional Valve

Product Series:SD8 Series Sectional Directional Valve

Packagingsize:45*45*17

Grossweight:36.00 kg

Availability: In Stock

633 Views are Looking for this Product

High Performance 8 Spool Directional Valve | Customizable for Hydraulic Systems detailed image

High Performance 8 Spool Directional Valve | Customizable for Hydraulic Systems detailed image

High Performance 8 Spool Directional Valve | Customizable for Hydraulic Systems drawing image

This is a high-performance, customizable 8-spool directional valve designed for a wide range of hydraulic systems used in material handling, construction, agriculture, and industrial vehicles. Its robust design and versatility make it ideal for applications like telehandlers, forklifts, mini-excavators, and more.

SD8 Series Sectional Directional Valve Parameters
Spool 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool, 8 Spool, 9 Spool, 10 Spool
Control Method Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick, Solenoid and Joystick, Manual and Joystick
Section 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section, 8 Section, 9 Section, 10 Section
Ambient Temperature Range -40°C to +80°C (-40°F to +176°F)
Operating Viscosity Range 12 - 400 mm²/s (12 cSt to 400 cSt)
Max Pressure 250 bar (3600 psi), 350 bar (5100 psi)
Rated Flow 90 L/min (23.8 US gpm)
Structure Type Sectional valve

Our High Performance 8 Spool Directional Valve, part of the SD8 series, is a manually controlled, sectional valve with 8 spools. It features a rated flow of 90 L/min (23.8 US gpm) and a maximum pressure rating of 350 bar (5100 psi), making it suitable for demanding applications. The valve operates within a viscosity range of 12 - 400 mm²/s (12 cSt to 400 cSt) and can withstand ambient temperatures from -40°C to +80°C (-40°F to +176°F). This valve is specifically designed for use in material handling, construction and earth moving, agriculture, and industrial vehicles, and is compatible with models like telehandlers, forklifts, mini-excavators, skid steer loaders, wheel loaders, backhoe loaders, tractors, front-end loaders, harvesters, balers, and sprayers. Its customizable nature allows for tailored integration into various hydraulic systems, making it a versatile solution for a wide range of applications.
