Mini Hydraulic Valve Factory Wholesale Supply: P80-G12-G34 Hydraulic Valves from the Source

Control Method:Manual

Spool:3 Spool

Rated Flow:80 L/min (21.2 US gpm)

Max Pressure:250 bar (3600 psi)

Inlet Port:G1/2

Outlet Port:G3/4

Port Size:G1/2

Vendor:BXHS

Product Type:Monoblock Directional Valve

Product Series:P80 Series Monoblock Directional Valve

Packagingsize:26*23*11

Grossweight:10.60 kg

Availability: In Stock

603 Views are Looking for this Product

Mini Hydraulic Valve Factory Wholesale Supply: P80-G12-G34 Hydraulic Valves from the Source detailed image

Mini Hydraulic Valve Factory Wholesale Supply: P80-G12-G34 Hydraulic Valves from the Source detailed image

Mini Hydraulic Valve Factory Wholesale Supply: P80-G12-G34 Hydraulic Valves from the Source drawing image

Our Mini Hydraulic Valve Factory offers a wide range of high-quality P80-G12-G34 hydraulic valves for various applications, including material handling, construction, agriculture, and industrial vehicles. We are a direct factory supplier, ensuring competitive prices and direct access to our products. Our 3-section monoblock valves offer a rated flow of 80 L/min and a maximum pressure of 250 bar. Contact us for wholesale inquiries.

P80 Series Monoblock Directional Valve Parameters
Spool 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool
Control Method Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick
Section 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section
Ambient Temperature Range -40°C to +80°C (-40°F to +176°F)
Operating Viscosity Range 15 - 75 mm²/s (15 cSt to 75 cSt)
Max Pressure 315 bar (4600 psi)
Rated Flow 80 L/min (21.2 US gpm)
Structure Type Monoblock valve

This P80-G12-G34 Mini Hydraulic Valve is a 3-section monoblock valve with a manual control system. It offers a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi). Designed for a wide operating viscosity range of 15 - 75 mm²/s (15 cSt to 75 cSt), it can operate in ambient temperatures from -40°C to +80°C (-40°F to +176°F). This versatile valve is ideal for various applications, including telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi- excavators, mini-excavators, and skid steer loaders. As a direct factory supplier, we offer wholesale prices and customized solutions to meet your specific needs. Contact us for all your Mini Hydraulic Valve requirements.

Mini Hydraulic Valve Factory Wholesale Supply: P80-G12-G34 Hydraulic Valves from the Source application image

Mini Hydraulic Valve Factory Wholesale Supply: P80-G12-G34 Hydraulic Valves from the Source packing image

Mini Hydraulic Valve Factory Wholesale Supply: P80-G12-G34 Hydraulic Valves from the Source company image

Mini Hydraulic Valve Factory Wholesale Supply: P80-G12-G34 Hydraulic Valves from the Source certification image
