720 Views are Looking for this Product
The P40-G38-OT Manual 1 Spool Monoblock Directional Valve is a high-performance hydraulic valve designed for various applications in industries such as material handling, construction, agriculture, and industrial vehicles. It features a compact monoblock design, manual control, and a rated flow of 40 L/min (10.5 US gpm), making it suitable for a wide range of hydraulic systems.
| P40 Series Monoblock Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick, Manual and Joystick |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Max Pressure | 250 bar (3600 psi) |
| Inlet Port | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Outlet Port | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Size | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type | Monoblock valve |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
**Product Features and Benefits:**
* Compact monoblock design for space-saving installation
* Manual control for precise and reliable operation
*Flow capacity of 40 L/min (10.5 US gpm) to meet the demands of various applications
* Durable construction ensures long service life and reliability
* Versatile design compatible with a wide range of hydraulic systems
**Applications:**
The P40-G38-OT Manual 1 Spool Monoblock Directional Valve is commonly used in hydraulic systems for various applications, including:
* Material handling equipment, such as forklifts, telehandlers, and cranes
* Construction machinery, such as excavators, loaders, and graders
* Agricultural equipment, such as tractors, harvesters, and balers
* Industrial vehicles, such as sweepers, compactors, and waste handlers
