The P40-U78-U34-2OT-YW Manual 3 Spool Monoblock Directional Valve is a high-performance hydraulic valve designed for use in a variety of industrial applications. It features a compact and robust design, with a rated flow of 40 L/min and a maximum pressure of 250 bar. The valve is suitable for use with a wide range of hydraulic fluids, and has an operating viscosity range of 15 - 75 mm²/s.
| P40 Series Monoblock Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick, Manual and Joystick |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Max Pressure | 250 bar (3600 psi) |
| Inlet Port | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Outlet Port | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Size | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type | Monoblock valve |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
**Product Features and Benefits:**
* Compact and robust design
* Flow capacity: 40 L/min
* Maximum pressure: 250 bar
* Suitable for use with a wide range of hydraulic fluids
* Operating viscosity range: 15 - 75 mm²/s
* Manual control
* 3 spool design
* Monoblock construction
**Applications:**
The P40-U78-U34-2OT-YW Manual 3 Spool Monoblock Directional Valve is suitable for use in a variety of industrial applications, including:
* Material handling equipment
* Construction and earth moving equipment
* Agricultural machinery
* Industrial vehicles
