This CBHC-2063 63 cc/rev Hydraulic Gear Pump delivers rated pressure of 20 MPa (2900 psi) and max speed of 2500 r/min for heavy-duty machinery. Manufactured by a 25-year IATF 16949 certified factory, it ensures reliable performance for forklifts, loaders, and excavators with bidirectional rotation capability.
| CBHC Series Hydraulic Gear Pump Parameters | |
|---|---|
| Displacement | 32 cc/rev, 40 cc/rev, 50 cc/rev, 63 cc/rev, 80 cc/rev, 100 cc/rev, 25 cc/rev, 110 cc/rev |
| Rated Pressure | 20 MPa (2900 psi), 22 MPa (3190 psi) |
| Max Pressure | 25 MPa (3625 psi), 28 MPa (4061 psi) |
| Rated Speed | 2200 r/min |
| Max Speed | 2500 r/min |
| Rotation | L: Left (counter-clockwise), R: Right (clockwise), /: (Bidirectional) |
| Material | Cast Iron |
| Structure | External Gear Pump |
| Flange Version | SAE Flange |
| Shaft Type | H: Rectangle Spline |
**1. High-Efficiency Hydraulic Gear Pump Specifications**
- Delivers 63 cc/rev displacement with a rated pressure of 20 MPa (2900 psi) and max pressure up to 25 MPa (3625 psi), ensuring stable power output.
- Operates at a rated speed of 2200 r/min and max speed of 2500 r/min, featuring bidirectional rotation for versatile installation in complex hydraulic systems.
**2. Versatile 63cc Hydraulic Pump for Heavy Machinery**
- Specifically engineered for material handling and construction equipment, including forklifts, telehandlers, skid steer loaders, and backhoe loaders.
- Compatible with agricultural tractors, mini-excavators, and sweepers, providing seamless integration as a direct replacement for international mainstream brands.
**3. Reliable CBHC Series Gear Pump Quality Assurance**
- Produced in our 68,000 sqm facility with 260+ vertical machining centers, every unit undergoes 100% bench testing for pressure, flow, and sealing integrity.
- Certified under IATF 16949 and CE standards, with SGS detection and 25+ patents, guaranteeing oil cleanliness and dimensional accuracy via CMM inspection.
**4. Customizable Industrial Hydraulic Pump Solutions**
- Supported by 35+ engineers with 10+ years of experience, we offer comprehensive OEM/ODM services including custom castings, appearance design, and laser logo marking.
- Ideal for distributors seeking private label opportunities, our flexible customization ensures your brand stands out in the competitive global market.
**5. Factory Direct Sales & Global Supply Capability**
- As a professional manufacturer with 25 years of expertise and an annual capacity of 1,500,000 units, we provide wholesale direct sales with competitive pricing.
- Ensures secure logistics with rust-proof treatment and heavy-duty wooden crate packaging, supporting bulk orders for wholesalers and OEM partners worldwide.
