Production & Delivery
15-30 Days Production Lead Time
Innovation drives development Technology forges future
- Manual
- Pneumatic
- Electro-pneumatic
- Electro-hydraulic
- Solenoid
- Hydraulic
- Hydraulic and Manual
- Cable
- Joystick
- Solenoid and Manual
- Manual and Joystick
- 1 Spool
- 2 Spool
- 3 Spool
- 4 Spool
- 5 Spool
- 6 Spool
- 7 Spool
162 Views are Looking for this Product
The DCV40 6-spool monoblock directional valve is a high-performance hydraulic control solution engineered for precision and durability. Supporting up to 40 L/min and 350 bar pressure, this versatile valve is built to excel in extreme environments, making it an ideal choice for global OEMs and machinery distributors seeking reliable flow control.
| DCV40 Series Monoblock Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick, Solenoid and Manual, Manual and Joystick |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Max Pressure | 350 bar (5100 psi) |
| Inlet Port | G3/8, G1/2, SAE 8, SAE 14, 3/8 NPT, 1/2 NPT |
| Outlet Port | G1/2, M18×1.5, M22×1.5, SAE 8, SAE 14, 1/2 NPT |
| Port Size | G1/2, M18×1.5, M22×1.5, SAE 8, SAE 14, 3/8 NPT, 1/2 NPT |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Structure Type | Monoblock valve |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
The DCV40 Monoblock Directional Valve is designed to provide robust control for complex hydraulic systems in mobile and industrial machinery. Key features include:
- Exceptional Durability: Constructed in a single monoblock body for superior structural integrity and high-pressure resistance up to 350 bar.
- Versatile Connectivity: Multiple port configuration options (NPT, SAE, G-thread) to ensure seamless integration with various hydraulic systems.
- High Adaptability: Engineered for extreme temperature performance (-40°C to +80°C), ensuring operational reliability in both arctic and tropical climates.
- Precision Control: The 6-spool layout allows for multi-function management of attachments, ideal for heavy-duty equipment like excavators, loaders, and agricultural tractors.
- Customization & OEM Support: We provide professional manufacturing, OEM/ODM services, and wholesale support, tailored to meet your specific technical requirements and branding needs for global market distribution.
