The P40 series is a robust 3-spool monoblock directional valve featuring advanced solenoid and cable control. Engineered for a 40 L/min flow rate at up to 250 bar, it offers precise hydraulic fluid regulation for complex machinery requiring flexible operation.
| P40 Series Monoblock Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick, Solenoid and Joystick, Manual and Joystick, Solenoid and Cable |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Structure Type | Monoblock valve |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Rated Flow | 40 L/min (10.5 US gpm) |
| Max Pressure | 250 bar (3600 psi) |
| Inlet Port | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Outlet Port | G3/8, G1/2, M18×1.5, M22×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
| Port Size | G3/8, G1/2, M18×1.5, SAE 8, SAE 10, 3/8 NPT, 1/2 NPT |
Our P40-BOT-BQTW1-DCOT monoblock valve is engineered for high-performance hydraulic systems in demanding environments. Key benefits include: 1. Dual Control Versatility: Combines reliable solenoid actuation with flexible cable control for ergonomic operation. 2. Robust Construction: Designed to withstand extreme temperatures from -40°C to +80°C, ensuring durability in harsh industrial or outdoor settings. 3. Precision Engineering: Compact monoblock structure minimizes leakage paths while ensuring consistent flow control. 4. Highly Adaptable: Supports a wide range of port configurations (NPT, SAE, Metric, BSP) to seamlessly integrate into existing hydraulic circuits. This valve is ideal for mobile equipment, agricultural machinery, and industrial lifting platforms, offering a scalable solution for manufacturers seeking reliable, high-pressure flow control components.
