The P80-G12-G34-OT manual 4 spool monoblock directional valve is a highly versatile and durable component designed for a wide range of hydraulic applications. With a rated flow of 80 L/min (21.2 US gpm) and a maximum pressure of 250 bar (3600 psi), this valve can handle demanding hydraulic systems. Its compact monoblock design ensures easy installation and maintenance.
| P80 Series Monoblock Directional Valve Parameters | |
|---|---|
| Control Method | Manual, Pneumatic, Electro-pneumatic, Electro-hydraulic, Solenoid, Hydraulic, Hydraulic and Manual, Cable, Joystick, Manual and Joystick |
| Spool | 1 Spool, 2 Spool, 3 Spool, 4 Spool, 5 Spool, 6 Spool, 7 Spool |
| Ambient Temperature Range | -40°C to +80°C (-40°F to +176°F) |
| Structure Type | Monoblock valve |
| Section | 1 Section, 2 Section, 3 Section, 4 Section, 5 Section, 6 Section, 7 Section |
| Operating Viscosity Range | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| Rated Flow | 80 L/min (21.2 US gpm) |
| Max Pressure | 315 bar (4600 psi) |
| Inlet Port | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Outlet Port | G1/2, G3/4, M27×2.0, SAE 10, SAE 12, 1/2 NPT, 3/4 NPT |
| Port Size | G1/2, G3/4, M22×1.5, M27×2.0, SAE 10, 1/2 NPT, 3/4 NPT |
**Product Features and Benefits:**
* **Compact monoblock design:** Easy installation and maintenance
* **High flow capacity (80 L/min):** Suitable for demanding hydraulic systems
* **High pressure rating (250 bar):** Can withstand high system pressures
* **Manual control:** Precise and responsive operation
* **Wide operating viscosity range (15 - 75 mm²/s):** Can handle various hydraulic fluids
* **Durable construction:** Ensures long service life
**Applications:**
The P80-G12-G34-OT manual 4 spool monoblock directional valve is widely used in various hydraulic applications, including:
* Material handling equipment (e.g., forklifts, telehandlers)
* Construction and earth moving machinery (e.g., excavators, loaders)
* Agricultural machinery (e.g., tractors, harvesters)
* Industrial vehicles (e.g., sweepers, waste compactors)
